Editor's Desk
By Steve Litt
I happily used Micrografx Windows Draw from 1990 through 2001. Vector based,
trivially easy to use yet very powerful, it came with vector clip art sufficient
to make almost any cartoon, book cover, web graphic, etc. At lighting speed.
I figured I'd use it forever.
But then Richardson Texas based Micrografx sold the program to a company
that doesn't market it any more, and I switched to Linux, where it doesn't
run, not even with Crossover Office. I needed a new graphics program.
I've heard wonderous praise of dia, xfig, the OpenOffice drawing program,
and several others. None could touch the speed, ease and power of Micrografx
Windows Draw. Where would I find a suitable vector drawing program? The answer
was surprising.
It turns out that a raster graphics program, Gimp, is the best Linux replacement
for Micrografx Windows Draw.
Mgx Draw was wonderful because you could independently work with objects,
without harming the rest of the drawing. Gimp's layers isolate small pieces
of the drawing. Mgx Draw had bezier curves. So does Gimp. Mgx Draw could
easily draw ovals, rectangles, etc. So can Gimp.
Gimp falls far short when it comes to clipart. However, if I can retrieve
a face off from anywhere, I can put it on a layer, move it around until everything's
right, and get it done that way. No, Gimp isn't quite as fast as Mgx Draw,
but it's a whole lot faster better than most other graphic programs on Windows
and Linux.
And in many areas, Gimp exceeds Mgx Draw. Gimp has rulers, guidelines, zoom,
and varying brush sizes so that you can work to the nearest pixel. Gimp has
incredibly powerful image processing capabilities, such as the ability to
clean up scanned images and brighten up photos.
Most people think of Gimp as powerful but difficult. When viewed from the
right mindset, Gimp is incredibly easy. Just think layers. Lots of layers.
If you mess up one layer, just redo it.
Most Troubleshooters.Com graphics made after March 2001 were made with Gimp.
It's an excellent and highly productive product. It's free software. This
issue of Linux Productivity Magazine is devoted to making you a Gimp ninja
in an hour or so.
Dig in!
Help Publicize
Linux Productivity Magazine
By Steve Litt
Loyal readers, I need your help.
For months I've publicized Linux Productivity Magazine, expanding it from
a new magazine to a mainstay read by thousands. There's a limit to what I
can do alone, but if you take one minute to help, the possibilities are boundless.
If you like this magazine, please report it to one of the Linux magazines.
Tell them the URL, why you like it, and ask them to link to it.
I report it to them, but they don't take it very seriously when an author
blows his own horn. When a hundred readers report the magazine, they'll sit
up and take notice.
Reporting is simple enough. Just click on one of these links, and report the
magazine. It will take less than 5 minutes.
If you really like this magazine, please take 5 minutes to help bring it to
a wider audience. Submit it to one of the preceding sites.
Gimp Does it All
By Steve Litt
If I were stranded on a desert island with only one graphical tool, I pray
it would be Gimp. Gimp might not be easiest for specific applications, but
it can do just about anything. This article gives an overview of a select
few of Gimp's abilities. Gimp has MANY more abilities than discussed in this
article.
Scanned Doc Cleanup
You scan a document from Gimp with File->Acquire->XSane as follows:
Manipulate the XSane histogram so that you get all the colors in all their
intensities, but nothing more. The following is an example of an optimally
scanned yellow receipt scanned at 75 dpi for reduced web bandwidth:
The preceding is reasonably readable even though it's taken at very low resolution
(75dpi). Normally you'd go at least 150dpi to back up paperwork, but on the
web 75 is quite sufficient, because some of you still use dialup.
Speaking of bandwidth, the RGB or indexing of the preceding consumes way too
much disk space. You want to get this image down to grayscale. The only problem
is, if you simply grayscale it as-is, the human eye has a much harder time
distinguishing between print and background:
The solution is to first enhance the contrast and brightness, followed up
with a select-by-color clear to convert the background to white while still
leaving the print and its antialiasing intact. Step 1 is to enhance the brightness
and contrast of the grayscale image with Rightclick->image->colors->levels.
Here is the histogram shown on the levels screen:
In the preceding, most of the coloration falls in about half the band, while
the rest is nothing but outliers. To get the most intensity variation, pull
the limits in to the areas of concentration. That makes the contrast what
it should be. Then move middle arrow to the point where it gives the best
brightness. In my case, I didn't mess with the middle arrow because I can
always change the brightness later -- the contrast is what's important at
this point. Watch the image as you adjust. When everything's optimal, click
the OK button. The following is the histogram after tweaking the limits. Note
that the only thing that changed are the outer arrows immediately below the
histogram:
The preceding contrast tweak yields the following improvement in the image:
The preceding is readable, but we can do even better by whitening the background
while leaving the printing and its associated antialiasing alone. To accomplish
this, we use the select by color feature to select the background grays, and
then clear them. The trick is to get the background, but leave the print and
the antialiasing intact. This is best accomplished with a narrow fuzziness
threshold on a moderately dark part of the background, but that dark part
must be lighter than the lightest print. Here's the procedure:
- Rightclick->Select->ByColor
- Put the fuzziness threshold at about 15%
- Make sure selection mode is "Replace"
- In this example, click to the right of the 5552 in the bicycle vendor's
zip code. Because the 5552 is the lightest text, clicking on the backgtround
near it represents some of the darkest background that is still lighter than
the lightest print and its antialiasing. You'll notice all sorts of selection
lines.
- Rightclick->Edit->Clear
- Rightclick->Select->None to clear the selection lines.
- Save the file
The result of the preceding looks something like this:
The preceding is very readable, although the dark splotches are somewhat distracting.
For most purposes, this is sufficient. Notice that all remaining splotches
are darker than the gray shade you clicked on, meaning that clicking on them
will hurt the print or antialiasing, making it less readable. Further cleanup
will require selective work on specific parts of the image:
- Select and clear various parts that are obviously background
- Select by color inside specific selections containing the darker print.
To do that, use the rectangle, oval or bezier to make a selection around the
darker print, then select by color, but use the Intersect mode instead of
the Replace mode.
The following graphic shows after the hand clearing of the smudges and the
staple mark above the vendor name and address, the spots in the customer name
area, and the splotches running down the lower left side of the receipt:
The final step is hand selecting the darker text, and within those selections
only, using the select by color method to clear the surrounding gray without
harming the antialiasing -- a tricky proposition:
In the preceding, I had selected and then selected by color within those selections,
clearing the color selections. Speficially, I did this to the ORANGE CYCLE
at the top, and the word EDGEWATER and the zip code on the second line. You've
probably also noticed that this might have made it less readable. When cutting
it this fine, extreme care must be used. It's often better not to hand color
select.
The following screenshot shows the select by color properties screen.
Note that these techniques are much more effective at higher scanning resolutions.
At 150dpi it would have been much less pixelated and more readable, and even
the hand color selections would have been beneficial. At 300dpi you can get
some very readable sheets and still store them as grayscale.
Filling in Pdf
This is covered elsewhere
on Troubleshooters.Com, so there's no need to repeat the techniques here.
Suffice it to say that Gimp provides you with an effective way to take an
existing .pdf file, and "write over" it. The image quality will suffer to
some degree, but it's a way of getting the job done without paying for Adobe
Acrobat and performing licensing audits on it.
Web Graphics
Web graphics are quick drawings made primarily from geometric figures and
bezier curves. They're easiest done in top notch vector drawing programs,
but Gimp can do an excellent job in a pinch. The trick is to use a separate
layer for each drawing element so that if you make a mistake only that layer
need be redone. This is very similar to the object philosophy of vector drawing
programs.
The other precaution you need to take in Gimp is to size everything right
the first time, because it's difficult or impossible to correctly resize parts
of a drawing. Vectors are made to resize without jaggies -- raster graphics
are not. Perhaps it's best to draw a large drawing first, and if necessary
shrink it to 1/2, or 1/3, or 1/4 of the original size using the Rightclick->Image->ScaleImage
technique. What you don't want to do is blow up an existing image, because
if you blow it up by a factor of 2, 1 pixel becomes 4, and the picture is
grainy. Blowing it up or shrinking it by a non-multiple will likely lead
to ugliness, so keep it to integer factors or denominators.
An example of a simple web graphic is given later in this document, in the
Exercise: Creating a Web Graphic
article.
Photo Retouch
There are 2 kinds of photo retouch:
- Lighting correction
- Modifying the actual image
Lighting correction is easy enough. We've already discussed using the histogram
at Rightclick->Image->Colors->Levels to adjust brightness and contrast.
In a color picture it can even be used to make skin tones more natural.
Then there's changing what's really there. Who's this handsome devil:
Why, it's me, in my high school yearbook the year
I graduated. But where are the zits? My complexion wasn't bad, but it wasn't
flawless either. The photographer airbrushed out my zits. Some of my classmates
had serious complexion issues, but thanks to that photographer today they
can look at their yearbook pictures and see the good looks lying underneath
that temporary teenage problem.
|
 |
I once used Gimp remove a huge printer, a paper shredder, and a curtain from
a picture of our booth at CTS. Here was the original (reduced for bandwidth
considerations):
The picture to the right is the original booth
picture. Note the printer and paper shredder in the booth on our right, and
the curtain in the booth in the camera's foreground clutter the picture and
make it less effective.
|
 |
The picture to the right is the picture after
I cropped it, removed the printer and shredder, and the curtain in the foreground.
If you look VERY carefully you can see repeating fold patterns on the curtain
where the printer and shredder used to be. I copied parts of the curtain
over the areas formerly covered by the printer and scanner. I also copied
parts of the blue rug over the area formerly covered by the shredder.
I performed similar carpet copying on the curtain in the left foreground,
as well as restoring the pant leg and shoe of the man in the bluejeans and
blue shirt.
|
|
The result of my photo retouch is a much less cluttered photo, where your
eye is attracted specifically to our booth. In hindsight, I should have removed
the table appearing in the lower right. That would have removed any evidence
of our next door neighbors, it would have further focused attention on our
booth. Removing the bottom right table would have been a simple matter of
continuing the red/blue carpet line, and copying textures to the proper areas.
It would have been MUCH easier than the curtains.
Finally, I submit without comment, an original and Gimp-altered picture of
myself and the dog I had as a kid:
Quick Riffs
By Steve Litt
You draw some things over and over. This article tells you the fast way to
do so.
Using Rulers
If your name is Van Gogh or Van Rijn (Rembrandt to your friends), perhaps
you can draw everything freehand. For the rest of us, Gimp has included rulers.
The beauty of Gimp's rulers is that they show the current pointer location,
so you can align and drag with precision. Better yet, because Gimp scrolls
with the dragged pointer, you can set the magnification as high as you want.
Observe the following perfectly proportioned 3/4/5 right triangle as it is
built:
To the right is the starting point. The mouse pointer
isn't visible because this is a screenshot, but notice the arrow at the 5
pixel mark on the top ruler and the arrow at the 30 pixel mark on the left
ruler. That's where the pointer was, and where we start the triangle.
|
|
Here we've drawn a horizontal straight line. First
a point was made at the starting point, and then the Shift button was held
while the mouse was moved to x=5, y=10, at which time the mouse was clicked
to make the line. 40-10 is 30 -- the 3 side of a 3/4/5 triangle.
|
|
Next we press the Shift button again, and move
the mouse pointer to x=45, y=5, then click to create a horizontal line 40
pixels long, the 4 side of the 3/4/5 triangle.
|
|
Finally, we press the Shift button, move the mouse
back to x-5, y=40, and click in order to draw the hypotinuse and complete
the 3/4/5 right triangle.
We owe our precision to the use of the rulers, and the fact that the arrows
on the rulers tell our precise mouse pointer location. In real life we would
have increased the magnification to do this work. Even if the entire figure
spanned more than the window we're working in, it's OK, because the window
would have scrolled.
|
|
Using Layers
Without layers, Gimp would be a toy, and a frustrating one at that. If you've
ever used Microsoft Paint you know what I mean. When your drawing reaches
a certain level of complexity, the slightest mistake must be extensively reworked.
Layers bring immense power to Gimp. By placing individual picture components
on their own layers, you ensure that you never irretrievably overwrite anything,
and if you need to erase something, you don't erase the things the appear
over or under it.
You create a new layer with Rightclick->Layers->Layers_Channels_&_Paths.
This brings up a dialog box that looks like this:
Clicking on any of the eyeballs to the left of a layer makes that layer invisible,
and the eyeball disappears. To restore the layer to visibility, click where
the eyeball had been, and the eyeball reappears and the layer once again is
visible.
Clicking the new button (
) creates a new layer. Clicking the duplicate button (
) duplicates the currently
highlighted layer. The up and down buttons (
,
) send the layer toward the front or toward the back,
respectively. To delete a layer, highlight it and click the delete button
(
).
To draw on a particular layer, select that layer in the layer dialog box.
Be careful -- sometimes oversights lead to you're drawing on a different layer
than that intended.
If you want to make the background layer transparent, or any layer for that
matter, simply highlight the layer on the dialog, right click it on the dialog,
and choose "Add alpha channel". From that point on, clearing any material
on that layer leaves a transparency such that items on lower layers become
visible.
Construction Lines
Remember 10th grade geometry? In order to draw various geometric items, you
used construction lines, which are light lines serving as guides. Later, when
you studied drafting, you once again used construction lines. Construction
lines are vital in Gimp, because they allow you to place things exactly. In
Gimp, construction lines are limited to horizontal and vertical lines, which
is just fine with me. To place a horizontal construction line, click the
top (horizontal) ruler, then drag down to the appropriate place. To place
a vertical construction line, click the left (vertical) ruler and drag right
to the desired location.
Construction lines are dotted lines visible throughout all layers. They are
not printed, and are not visible in any saved format, EXCEPT IN GIMP. Gimp
saves the construction lines as part of the XML format of the .xcf fileformat.
To move a construction line, click and drag it. To delete a construction line,
click and drag it to the ruler.
Notice the spacing slider. This is for drawing dotted lines. Try picking
a brush size, and then slide the slider to 1000. Draw, and you'll see a dotted
line. This becomes more important when you learn how to draw a straight line.
Line Widths
The width of things drawn by all drawing tools, as well as Rightclick->Edit->Stroke
are defined by Gimp's "Brush width". To access and change the brush width,
do this:
- Rightclick->Dialogs->Brushes
- Click the desired brush width
1x1 is for fine lines, but is not very visible in web graphics. 3x3 is better
for tiny web graphics, with the larger sizes even better when precision isn't
needed.
Lines
There are 2 kinds of lines -- straight and nonstraight. Nonstraight lines
can be drawn freehand with the pencil tool (
) and various other paintbrushes and the like,
or drawn curve by curve using the Bezier curve tool (
). Straight lines
are drawn with the pencil tool as follows:
- Click the pencil tool ()
- Click the desired startpoint
- Pressing the shift key, move, do not drag, the mouse pointer to the
desired endpoint.
- Click to draw the line.
The endpoint becomes the startpoint for any subsequent lines, so to draw
a subsequent line, just keep pressing the shift key, move the mouse to the
next endpoint, and click.
Rectangles
Most graphics programs have specific tools for rectangles. Gimp doesn't,
instead relying on the rectangular selection tool. Once you've selected a
rectangular region, you can go ahead and either draw a line around it, fill
it, or both.
Drawing a Hollow Rectangle
- Rightclick->Dialogs->Brushes
- Choose the desired brush size
- Choose your desired foreground color
- On the Gimp toolbox, click the rectangular select tool (
)
- Click and drag a rectangle
- Rightclick->Edit->Stroke
- You now have a hollow rectangle
Drawing a Filled Rectangle with no Border
- Choose your desired foreground color
- On the Gimp toolbox, click the rectangular select tool ()
- Click and drag a rectangle
- Within the selection, Rightclick->Edit->Fill_with_FG_color.
- You now have a filled rectangle with no border.
Drawing a Filled Rectangle with a Border
Presumably you want the border a different color than the fill. Otherwise
you'd just make a wider filled rectangle without a border.
- Make the foreground color the desired fill color
- Draw a filled rectangle with no border, as discussed previously in
this section.
- Make the foreground color the desired border color
- Select the desired brush size
- Rightclick->Edit->Stroke
- You now have a filled rectangle with a border.
WARNING: Order counts. If you make the border first, the fill covers the
inner half of the border, which probably isn't what you want.
Square
A square is just a special case of a rectangle. To create a square selection,
start drawing a rectangular selection, but while you're dragging, depress
the keyboard shift key. The rectangle will become square, and any further
dragging will shrink or grow, but will stay constrained to a square as long
as the shift key is depressed. Do not press the shift key before starting
to drag, or the new square will be added to any existing selection, which
probably isn't what you want.
Once your square selection is created, you can create filled, bordered, or
combination squares exactly like you would with a rectangle.
Ovals and Circles
Creating ovals is exactly the same as rectangles, except you use the oval
selection tool (
).
Creating a circle is similar to a square. After starting to drag the oval,
depress the shift key and continue dragging. The oval changes to a circle,
and then as you drag further, it stays constrained to a circle.
2 Ways to Start an Oval
Normally, when you drag a circular selection, the starting point is a right
angle tangent to the oval's sides. For instance, if you know where you want
the top and left extremes of the oval, you can place construction lines at
the intended top and left extremes of the oval, and start the oval at their
intersection. The following sequence shows the method:
|
|
|
Starting the oval selection
|
Continuing to drag
|
The finished oval selection
|
But sometimes you want to start the oval at its center. Certainly, if you're
drawing a bicycle, you'll want to center its wheel at the bottom of the fork.
To start at the center, do the following:
- Click at the intended center, and drag.
- Press the Ctrl key, and drag some more. Note that the oval jumps so
its circle coincides with the starting point.
- Release the mouse when the oval's radii are correct.
Warning: Order is significant. If you press the Ctrl key first, it might still
work, but if there was a previous selection, the two selections will be subtracted.
Also, pressing the Ctrl key first precludes the ability to create a circular
selection -- the attempt will disappear when you release the mouse.
Starting a Circle at the Center
This is not obvious, but once you know how, it's easy.
- Click at the intended center, and drag.
- Press both the Ctrl and Shift keys, and drag some more. Note that the
oval becomes a circle and jumps so its circle coincides with the starting
point. Note that you can press the Ctrl key first, the Shift key first, or
both at the same time.
- Release the mouse when the circle's radius is correct.\
Irregular Selections
You can create irregular selections with the Bezier tool (), the hand select
tool (
), the select contiguous tool (
), and the
Rightclick->Select->Select_by_color functionality.
In my opinion, the hand select tool isn't useful because few people have hands
steady enough to hand select accurately.
The select contiguous tool is quick and handy because when you use it and
click on a part of an image, it selects everything of the same or similar
color to the pixel clicked, as long as the same or similarly colored pixels
are contiguous. Try it and you'll see. You might wonder how similar is considered
similar. That's up to you. Doubleclick the select contiguous tool and you'll
see a Threshold slider. If set to zero, only exactly matching colors are selected.
If set to 255, all non-transparent colors are selected. Experiment with this
tool.
What if you want to select certain colors, whether or not they're contiguous
to each other. In that case, use the Rightclick->Select->Select_by_color
functionality. That series of keystrokes brings up a dialog box where you
can change the fuzziness threshold, and define how any existing selection
is modified. You can add, subtract from or replace the current selection,
or you can intersect with it. The intersection is particularly handy because
it gives you a way to constrain your select by color to a certain area. This
is ideal for cleaning up dirty scans.'
I've saved the best for last. The Bezier tool gives you the ability to "connect
the dots" to form a selection. Better yet, if you drag the dots, it drags
the curve points associated with the dots. Still better, if you Ctrl+drag
the dots, it moves the dots itself. But wait -- there's more. If you Shift+drag
the curve points, it moves only that curve point, creating discontinuous curves
for angles and cusps.
Working with Selections
The following is a pretty good summary of simple selection operations:
Task
|
Method
|
Shortcut
|
Clearing
|
Rightclick->Edit->Clear
|
Ctrl+K
|
Filling with foreground color
|
Rightclick->Edit->Fill with FG color
|
Ctrl+,
|
Filling with backround color
|
Rightclick->Edit->Fill with BG color |
Ctrl+.
|
Copying the contents
|
Rightclick->Edit->Copy
|
Ctrl+C
|
Cutting the contents
|
Rightclick->Edit->Cut
|
Ctrl+X
|
Pasting
|
Rightclick->Edit->paste
|
Ctrl+V
|
Move the contents
|
Drag the selection
|
|
Move the selection itself,
not the contents
|
Alt+drag the selection
|
|
Compound Selections
You can add to selections or subtract from selections, thus growing and shrinking
them, or making them other than rectangular or elliptical. Selections needn't
be contiguous.
To add selections, create a selection, then press the shift key and create
a second. The two are added. If they join at any point, it becomes one selection
area. If not, it becomes two selection areas, but the distinction is not
meaningful, because any action taken on one will be taken on the other.
To subtract selections, press the Ctrl key while drawing the selection to
be subtracted. Any area of overlap is deleted from the original selection.
Any area of the new selection not overlapping the old is ignored.
Note that when pressing the Shift or Ctrl keys while a selection tool is
active places a tiny plus or minus sign by the mouse pointer.
It's important to remember that Shift and Ctrl do double duty in selections.
Shift makes rectangles square, and Ctrl makes selection grow around the center.
To add and subtract selections without these additional properties, release
the Shift or Ctrl key after dragging a little bit. Once again, order is important.
To add or subtract, press Shift or Ctrl first, then drag the selection. To
select squares or select around a center, drag first, then press the Shift
or Ctrl key.
One vitally important compound selection method is Rightclick->Select->Select_by_color.
Let's say you want to change your white background to a blue background.
You can't do it with the bucket tool (
), because you'd need to click into every enclosed
area of white. If there's much printing, that quickly becomes prohibitive.
Instead, use the select by color functionality.
- Rightclick->Select->By_color
- On the revealed dialog box, choose Replace mode and set the Fuzziness
threshold to a low number. 0 is ideal, but if that would damage some of the
antialiasing, make the number something under 10.
- Set the Gimp background color to the background color you desire for
the image.
- Rightclick->Edit->Fill_with_BG_color
Selection Tricks for Impressing the Masses
If you doubleclick any tool on the Gimp toolbox, you're presented with a dialog
box concerning the tool. The dialog boxes for all the selection tools contain
a checkbox called "Feathering", which, when checked, enables a slider. The
farther left you slide the slider, the more pronouncedly fill operations are
blended with the existing background. Let's use that to make a blue sphere.
Step 1 is to make the sphere by filling a 240 pixel diameter circle with #000099:
That's nice, but it's a circle, not a sphere. Let's put a reflection in the
upper right part of the sphere. Change the foreground color to #0000FF. Then
doubleclick the circular selection tool, check the Feather checkbox, and set
the Radius slider to 50. Now create a 48 pixel circular selection in the
upper left, then Rightclick->Edit->Fill_with_FG_color:
Now we'll make an even lighter highlight inside this one. Set the foreground
color to #9999FF. Rightclick->Select->Shrink, and shrink by 12 pixels,
which is half the current radius. This shrinks the circular selection, but
keeps the center in the same place. Now Rightclick->Edit->Fill_with_FG_color:
Now set the foreground white (#FFFFFF), shrink the selection by 6 pixels (half
the current), and again fill with foreground:
Cropping properly, here's the resulting sphere:
Note that the addition of the highlight gives the ball dimension.
Filling Without Selections
We've already discussed various ways to fill a selection. Occasionally you
want to fill without a selection. To do that use the bucket tool (). Sometimes the bucket
tool's fills everything within the current layer or selection, whichever
is smaller. That's not what you want. You want to fill everything within
a contiguous area of similar color. If this happens to you you can change
its behavior. Doubleclick the bucket tool to produce its dialog box:
Click the Sample Merged checkbox, and it the bucket fills contiguous similarly
colored areas. To define how similar is "similar", move the Threshold slider.
Annotating
This is simple. When annotating any figure, create a layer for the text. Sometimes
you might want two layers. For instance, if you're creating a street map,
you might want one layer for names of north-south streets, and another for
east-west streets. That way the street text won't overwrite other street text.
Scanning Tips
By Steve Litt
Gimp is the ideal front end for scanning. Once your Sane compatible scanner
is hooked up and running, install xsane-gimp. Consult your distribution for
details.
Now you're ready to scan. From the Gimp toolbox, File->Acquire->XSane:'dev'usb'scanner0.
Your scanner might have a different name, but you get the idea.
Now you're brought to XSane. Set the color and DPI to your desired. Be sure
to enable the preview mode, take a preview shot, crop to the area of interest,
then tweak the histogram to include only colors and intensities existing in
the photo. By including only those colors and intensities, you can vary the
contrast over every bit of every byte of your color depth. The resulting scan
goes right into Gimp for editing.
We've already discussed fixing up scans and materially altering images, so
let's discuss one last bastion of photographs: brightening and cleaning up.
Note that this applies not only to scanned photos but also to digital photos
downloaded directly to your computer.
Brightening a Photo
Few of us are professional photographers using professional equipment, so
most of our photos are too bright, too dark, or washed out (not enough contrast).
Fortunately Gimp can help. Using the histogram techniques you used in article
Gimp Does it All, bring the input level
pointers in to exclude areas with little or no color and intensity representation.
This dramatically increases your contrast without making things too black
and white. Then move the middle pointer to adjust the brightness.
Gimp for Photo Forensics
Remember the picture of my dog and me?
What's in that room behind my dog and me? Let's find out..
The first step is to crop out everything besides that room (but not deleting
any of the room). Use the Bezier select to select out myself, the dog, and
everything foreground of that room. Next, I use the Bezier select to select
everything in the room, but not boy, dog or walls. I first selected around
the whole dog, then between her legs. With each selection, I chose Rightclick->Image->Colors->Levels
and brought the outer arrows in line with the intensity limits. As a last
step, I doubled the size of the drawing for better display on this website.
Here's the result:
Several things are now clear. There's a piece of furniture, probably light
colored, behind my shoulder. In fact, I recognize it as an all-in-one console
audio/television unit my parents bought before I was born. Something tall
and square or cylindrical rests atop that unit. There's a window with drapes
behind the dog. The window is open, so this must have been taken in the summer.
Or maybe not... The window is completely dark, so it must have been taken
at night. There appears to be a plant behind my dog's rear end, although
I don't remember such a plant from my childhood.
What I've done is selected only the dark areas for enhancement, and because
these dark areas had a very narrow range of intensities, I was able to spread
that narrow band across all 255 levels of grayscale color, thereby significantly
enhancing them.
Would it be possible to peer out the window? Let's try. I rectangularly select
the window, then intersect select by color, 15% fuzziness threshold, to select
the glass parts of the window, which are the darkest parts, then use the
levels histogram to enhance contrast, and blow it up by a factor of 2 (any
more pixelates beyond recognition). Here's the result, suitably cropped:
I've used this technique to reveal important people stuck in the background
of a flash photo, and to reveal almost hidden writing on signs. On one Troubleshooting
Professional Magazine photo, I used it to enhance a flipchart with a blank
sheet covering a sheet with writing, such that the writing showed through.
I doubt this was visible to the naked eye, but through the technology of
Gimp I was able to capture it.
Is it my imagination, or is that a Christmas tree in the window? Could it
be a reflection of our Christmas tree? Or could it be the neighbors' Christmas
tree? As I remember, you could see in the neighbors' window through our window.
I rescanned the photo at 1200, scanning just the window and its surroundings,
adjusting contrast and brightness with the sole purpose of seeing out
the window. Here's the result:
The big lump covering the bottom left is my dog's rear end. Everything else
is the window and dressings. Only the window panes have been super-enhanced.
Well -- it's not Christmas. It's obviously not a reflection of our Christmas
tree, and there's no window frame from the neightbors' house. What it looks
like is fairly dense bushes, and maybe trees, between our house and the neighbor's.
One can't be sure, because at this enhancement level there are plenty of
artifacts. For instance, observe the point of light at the upper right of
the left most vertical pane, and note the line proceding left throughout
the whole leftmost vertical pane, and extending onto the curtain itself.
It looks like a tree branch, but trees don't go through glass. There are
many specs of light. Are they reflected moonlight? Probably not -- things
are lighter toward the right (which corresponds to the front of the house).
Perhaps there was a street light illuminating the bushes. As far as all the
specs of light, perhaps they are gaps through the bushes where light got
through. I just don't know.
Remember that plant I saw in the picture of the room. In this window picture,
that plant is almost certainly not there. What is there is some sort of shadow,
perhaps from another window with light shining through other bushes.
The point is this. I took a 30 year old black and white photo taken with
a Brownie Hawkeye box camera, stored in dusty circumstances for years, bent,
curled, and exposed to polution, and made a reasonable deduction of what
was out the window in a photo whose subject was not the window, nor the dark
room containing the window, but the dog and boy in front of the room. I know
the television guys from CSI could do this, but who'd have thought that a
guy with Gimp could do this type of investigation?
Exercise: Creating a Web
Graphic
By Steve Litt
This is the web header graphic from the original Troubleshooters.Com in July
1996:
It was created in Paintshop Pro 3. There are some extra pixels on the extreme
right, but the visible part is 610x110 pixels. Note the "jaggies" in the printing.
We'll try to do better by antialiasing. Likewise, the gradient between violetish
blue and light tangerine blue occurs in distinct lines. Although this produces
the tiniest files, we'll also show you how to create a much smoother gradient.
In this exercise we'll duplicate this graphic in Gimp.
The first step is to run Gimp, and create a new RGB file whose dimensions
are 610x110. Next, create a layer called Border. On that layer, create a 14
pixel wide rectangular selection at each border, and fill each selection with
the border color, which is #008000. Save as tc.xcf, and it should look like
this:
Next, create a layer called BorderDecorations. This border will contain the
highlights and lowlights creating the 3D effects of the border, in effect
making it like you're looking out a window at the mountains. What we'll do
is measure various decorations on the original, and dupicate them on the BorderDecorations
layer, which will go above the Border layer. Let's start with the easiest
stuff. On top and to the left is a lighter area that is 4 pixels wide. We
know it's 4 pixels wide because we can make a selection, and while we're
dragging the selections we can see the selection dimensions in the lower
left. Here's a screenshot showing what I mean:
Using the eyedropper tool on the lighter left and top borders of original,
we find out that its color is #00c000, 4 pixels each, so using rectangular
selections and fill we place those on the BorderDecorations layer. Here's
the result:
Next, put the black border decorations on the same layer, at the bottom and
right, 4 pixels wide:
Notice that the black overwrites the light green, instead of them feathering
in on each other. Set a brush width of 1 pixel and mitre the corners by creating
triangles with the Bezier tool:
Now create the 2 pixel inside decorations: Black on the left and top, white
on the right, and #68c800 on the bottom:
At this point you're done with the Border and BorderDecorations layers. Your
next layer will house the gradient in the sky. It's a slightly violet blue
on top, and an almost tangerine blue on the bottom. Create a layer called
Gradient below the Border layer.
The first step is to get the colors at the extremes of the gradient. Using
the eyedropper tool on the original, we see that the top is #b5deff, while
the bottom is #f7f7f7.
Create a selection that does not include the border pixels, because you want
your entire gradient to occur only in the visible area. Doubleclick the gradient
tool (
) (also called the Blend Tool). That brings up
the properties for the gradient tool:
Notice that the blend is foreground to background. This is important, because
it determines which way we drag the tool.
Close the tool options screen. Now singleclick the blend tool (gradient tool)
(). Now, on the Gradient layer, place the cursor
approximately in the center of the selection, at the very top. Now Ctrl+Drag
down to the very bottom of the selection. Release the mouse and your gradient
appears, as shown following:
Now create a layer called "Mountains", above the "Gradient" layer. You'll
put the mountains on this layer. To save time, just download and save the
following graphic:
Open the preceding graphic in Gimp, Edit->Copy, and then paste it onto
the Mountains layer of the graphic you're creating. Move it so it butts up
against the bottom inside border, and the left inside border. The result should
look like this:
Now you need the writing. To prevent a trademark violation (Troubleshooters.Com
is now trademarked), we'll call this MyDomain.Cxm. Create a new layer, above
the Mountains layer, called "Text".
Remember how jaggy the original writing was? We're going to do better by putting
the writing on a layer whose color is the average color of the gradient. In
order to find the average color of the gradient, click with the color picker
tool (eyedropper) about half way between the top of the sky and the bottom
of the sky on the Gradient layer. This approximates the average color. Just
so we're on the same page, make it #d3e9fb.
Now go to the Text layer and fill the whole layer with that color. Make sure
that the gradient now looks like a uniform color. Next, make the background
color that color (#d3e9fb), and the foreground color black.
Now, when we use Gimp's Text tool, it will antialias with respect to the background
color, which just happens to be the average gradient color. Click the Text
tool, pick Helvetica 48 Bold Oblique, and in the text field type "MyDomain.Cxm".
Click OK, and then move the text (which is selected), to center it horizontally,
and between the border and mountains. Click with the rectangle tool to anchor
the new text on the Text layer. You'll notice that there are no visible "jaggies".
If you zoom the graphic, you'll see that the borders of the text are blended
from the black of the text to the lightblue of the #d3e9fb. This is how antialiasing
works.
Now it's time to get rid of the uniform #d3e9fb, revealing the gradient beneath.
Being sure you're still on the Text layer, right click, choose select->ByColor.
Make the fuzziness threshold 0, because we want to delete only #d3e9fb, not
any of the very closely related antialias colors. Be sure the selection mode
is "Replace". Now click on the image where there's nothing but #d3e9fb, and
notice that all of that color (and none of any others) are selected. Now rightclick
and choose Edit->Clear, and all #d3e9fb on the Text layer will be cleared
to transparent, revealing the underlying gradient. Finally, rightclick and
select Select->None to remove all selections. Your graphic now looks like
this:
If you don't mind high bandwidth, you're done. Just convert to an RGB jpeg.
My webmastering philosophy is to make the site useful for the least common
denominator likely to be surfing the net. That means 28K modem. You can reduce
the size of the graphic by making it 255 or 16 colors and saving it as a .gif
or .png. The smallest file you could make is to reduce it to 16 colors, no
dithering, and save it as a .png. That will come in at around 2800 bytes,
but the gradient will have lines much like the original. If you had saved
it as a .gif, it would have been about 3700 bytes, and had lines. A much better
solution would be to reduce it to 255 colors, Floyd-Steinberg dithering, saved
to a .png. That comes in at 4700 bytes, but the graphic is beautiful. Saving
it to .gif is also beautiful, but it's over 7000 bytes. Note that you can
play games with .png compression, but of course there's a quality tradeoff.
To color reduce in Gimp, Rightclick->Image->Mode->Indexed and fill
in the proper values.
Fixing the Gradient
If you notice, the gradient of the new file is darker than that of the original
because the original's light colors extended farther into the sky. The reason
is that our gradient extended evenly from border to border, whereas the original
took into account the mountains. To make the new one more like the original,
clear the Gradient layer, set the foreground to #b5deff and the background
to #f7f7f7. Experiment with dragging the gradient tool only part way down,
and you'll notice that the gradient midpoint is higher.
Once you've got the gradient you want, ideally you'll redo the text step so
that your antialiasing matches your new gradient.
Summary
You've just used Gimp to create a somewhat complex web graphic. Believe me,
it was much harder to create that same graphic in Paintshop Pro 3. In Gimp,
you use layers to build individual parts of the image, so that you never
faced a situation where a single slip could compromise the whole drawing.
By using layers liberally, you also gave yourself more room to work. You
accomplished the following:
- Used the eyedropper to find the colors of the original
- Measured distances using rectangular selections
- Built borders by filling rectangular selections
- Created mitres by creating triangular selections with the bezier
tool
- Created a gradient using the gradient tool
- Created antialiased text adjusted to the midpoint of the gradient
- Converted an RGB image to an indexed image for smaller filesize
- Learned the color depth tradeoffs
This serves as a good example of web graphic creation.
Life After Windows: What's a Good Graphics
Program Worth?
Life After Windows is a regular Linux Productivity Magazine column,
by Steve Litt, bringing you observations and tips subsequent to Troubleshooters.Com's
Windows to Linux conversion.
By Steve Litt
Many friends tell me that Photoshop is the best product on the market, and
you can do absolutely anything with it. Adobe sells it on their website for
$649.00 -- a bargain for software that can do absolutely anything and is "the
best there is".
Except that you don't know what you're buying for $649.00, do you? Are you
buying the right to use it forever? For 3 years? For 1 year? Are you buying
the right to use it on any single computer, or is the purchase locked to
a certain piece of hardware? If your company is purchased or merged, can
the new company use your $649.00 worth of "the best there is", or do you
need to pay again? Do you have the right to publicly evaluate the software,
or is that prohibited by the Adobe license. You don't know until you've paid
your $649.00 and read through the click-through license. If you read through
the license and don't like its provisions you can always return it. Yeah
sure.
So in reality, you don't know whether Adobe Photoshop is a bargain or a ripoff.
It's much easier to estimate the worth of Gimp. You own it forever, you can
use it on every computer in your company and those of 1000 or so of your
friends and customers. Many Gimp and Photoshop users compare the two as being
at least somewhat equivalent in quality and functionality.
Sounds to me like Gimp is worth $649.00. Or maybe more -- you can use it
on 1000 computers or 1,000,000 computers -- doesn't matter. Imagine that
-- a perpetual site license for only $649.00. Well, actually, $0.00. It's
free, both as in speech and as in beer. But Gimp is worth thousands, ESPECIALLY
if you're a large company with many users. Does Gimp have all Photoshop's
features? Probably not. Is Gimp as fast to use as Photoshop? Maybe, and maybe
not. But for most, Gimp is good enough, and you know what you're buying (scuse
me, receiving).
Here, in a new browser window (shrink
it) is a graphic from the Photoshop web page (shrink . Do you think it would
be that hard to do in Gimp?
I'll do it as a 200 x 200 rather than 50 x 50, because it's easier to work
with. Then I'll shrink it.
I won't use the background layer for anything. The next layer above that
will be what I call the construction line layer. I create line segments for
each leaf and for the stem:
I make a layer for each leaf, and a layer for the stem. I put the proper
colors on each leaf with select, fill, airbrush, etc. Finally, for each leaf
I used a blur filter to get rid of jaggies and make it look less like a computer
drawing. At 200x200 pixels, here's the result:
And here it is again, this time shrunk down to 50x50 to match Adobe's own
graphic:
OK, it's not 100% exact, but then again, I'm a Geek, not an artist. I'm also
not a Gimp authority. The point is that Gimp can do pretty much anything,
and when you obtain it, you know exactly what you're getting. To summarize:
- The best in the industry: $649.00.
- A program that can do anything: $649.00.
- Knowing what you're getting: Priceless.
Steve Litt is the author of the course
on the Universal Troubleshooting Process. He can be reached at his email address.
Letters to the Editor
All letters become the property of the publisher (Steve Litt), and may
be edited for clarity or brevity. We especially welcome additions, clarifications,
corrections or flames from vendors whose products have been reviewed in this
magazine. We reserve the right to not publish letters we deem in bad taste
(bad language, obscenity, hate, lewd, violence, etc.).
Richard Stallman Responds to the
10/2003
Linux Productivity Magazine
Note: This letter was written by Richard Stallman,
and is used herein with his permission.
Please contact Richard for any reprint rights.
Note: When Richard references article "Music on Linux",
I believe he's referring to the article titled "Genesis of an Itch" |
The article "Music on Linux" contains a general statement
about free
software which is inaccurate.
It is said that every free software project begins with
a programmer "scratching
an itch". In other words, he needs to do a task, or do
the task better, and
no existing software accommodates that end.
People do say this, but it is not correct. Many free programs have
this kind of motivation, but many others do not. This is not why we
have GNU Emacs, or BASH, or GCC, or GAS, or GNU libc, or GNU
Classpath, or Guile, or GNOME. Those programs, and many other parts
of the GNU system, were written for a reason deeper than practical
convenience. We developed them for the specific purpose of winning
the freedom to cooperate, for ourselves and for all computer users.
More generally, the article seems to adopt a general attitude of
judging programs solely by their technical qualities, not paying much
attention to the question of how they treat the user's freedom. For
instance, the article describes MS Word in 1996 as "the best outliner
ever". It is clear that "best" is meant in a purely practical sense,
since when judged in terms of freedom, MS Word has always been down
with the worst.
It is said, with rather more justification than the other statement
has, that those who don't defend their freedom will lose it. The
first step is to stop thinking that a program that tramples the user's
freedom can be a good thing. Start resenting blows to your freedom,
and presently you will find yourself ready to defend it.
As a secondary point, the when the term "Linux" is used in this
article, it really refers (in all cases as far as I can see) to the
combined GNU/Linux operating system rather than Linux itself. Would
you please give the GNU Project equal mention in the name of the
system whose development is primarily our work?
|
Editor's Note: When I refer to GNU/Linux as "Linux", I'm using
an abbreviation.
The operating system I use on a daily basis is comprised of the Linux kernel
combined with many GNU utilities and programs, and utilities and programs
from other sources. We GNU/Linux users owe everything to the GNU project
and
the FSF. Here are some articles I've written on the subject:
|
Submit letters to the editor to Steve Litt's email address, and be sure
the subject reads "Letter to the Editor". We regret that we cannot return
your letter, so please make a copy of it for future reference.
How to Submit an Article
We anticipate two to five articles per issue, with issues coming out monthly.
We look for articles that pertain to the Linux or Open Source. This can be
done as an essay, with humor, with a case study, or some other literary device.
A Troubleshooting poem would be nice. Submissions may mention a specific product,
but must be useful without the purchase of that product. Content must greatly
overpower advertising. Submissions should be between 250 and 2000 words long.
Any article submitted to Linux Productivity Magazine must be licensed with
the Open Publication License, which you can view at http://opencontent.org/openpub/.
At your option you may elect the option to prohibit substantive modifications.
However, in order to publish your article in Linux Productivity Magazine,
you must decline the option to prohibit commercial use, because Linux Productivity
Magazine is a commercial publication.
Obviously, you must be the copyright holder and must be legally able to
so license the article. We do not currently pay for articles.
Troubleshooters.Com reserves the right to edit any submission for clarity
or brevity, within the scope of the Open Publication License. If you elect
to prohibit substantive modifications, we may elect to place editors notes
outside of your material, or reject the submission, or send it back for modification.
Any published article will include a two sentence description of the author,
a hypertext link to his or her email, and a phone number if desired. Upon
request, we will include a hypertext link, at the end of the magazine issue,
to the author's website, providing that website meets the Troubleshooters.Com
criteria for links and that the author's
website first links to Troubleshooters.Com. Authors: please understand we
can't place hyperlinks inside articles. If we did, only the first article
would be read, and we can't place every article first.
Submissions should be emailed to Steve Litt's email address, with subject
line Article Submission. The first paragraph of your message should read as
follows (unless other arrangements are previously made in writing):
Copyright (c) 2003 by <your name>. This material
may be distributed only subject to the terms and conditions set forth in the
Open Publication License, version Draft v1.0, 8 June 1999 (Available
at http://www.troubleshooters.com/openpub04.txt/ (wordwrapped for readability
at http://www.troubleshooters.com/openpub04_wrapped.txt). The latest version
is presently available at http://www.opencontent.org/openpub/).
Open Publication License Option A [ is | is not] elected,
so this document [may | may not] be modified. Option B is not elected, so
this material may be published for commercial purposes.
After that paragraph, write the title, text of the article, and a two sentence
description of the author.
Why not Draft v1.0, 8 June 1999 OR LATER
The Open Publication License recommends using the word "or later" to describe
the version of the license. That is unacceptable for Troubleshooting Professional
Magazine because we do not know the provisions of that newer version, so it
makes no sense to commit to it. We all hope later versions will be better,
but there's always a chance that leadership will change. We cannot take the
chance that the disclaimer of warranty will be dropped in a later version.
Trademarks
All trademarks are the property of their respective owners. Troubleshooters.Com(R)
is a registered trademark of Steve Litt.
URLs Mentioned in this Issue
_
